SVBONY SV545 203mm f/4.5 Petzval APO Astrograph
The SV545 is a 45mm-aperture imaging lens with 203mm focal length and an f/4.5 Petzval optical design. Built-in field correction, a helical focuser and a lockable camera rotator make it a compact option for wide-field deep-sky imaging.
SVBONY SV545 203mm f/4.5 APO Astro Camera Lens (Full-Frame Ready)

The SVBONY SV545 is a compact, fast 203mm f/4.5 APO astro camera lens designed for wide-field deep-sky imaging. Its Petzval optical layout (5 elements in 3 groups) includes a built-in field flattener to help deliver sharp, well-corrected stars from centre to edge—ideal for modern CMOS cameras and wide-field nebula work.

Key Features
- Fast f/4.5 aperture for brighter frames and shorter exposure times
- Integrated field flattener supports edge-to-edge clarity without adding extra optics
- 44mm image circle for full-frame coverage (also excellent with APS-C)

- Fully Multi-Coated (FMC) optics to enhance transmission and reduce reflections

- Smooth integrated helical focuser for precise manual focusing

- CAA rotator for smooth framing rotation with secure locking
- M48 interface + 2" filter support for simple camera/filter integration

Built-In Field Flattener: Cleaner Stars Across the Frame

The SV545’s Petzval design incorporates a dedicated correcting group to flatten the field, helping to keep stars round and tight across the sensor—particularly valuable for wide-field mosaics, large nebulae, and full-frame imaging.
Full-Frame Imaging with a 44mm Image Circle

With a 44mm image circle, the SV545 is designed for full-frame cameras and delivers a generous illuminated field for wide panoramas of the Milky Way and large deep-sky targets.
Helical Focus + CAA Rotator for Easy Framing

The integrated helical focuser offers smooth manual control, while the CAA rotator enables full-angle rotation to dial in composition—then lock it down for stable imaging.
M48 Interface & 2" Filter Support

The rear connection uses an M48x0.75 male thread and supports a 2" filter holder, making it straightforward to add filters and connect common imaging accessories.
What’s Included

The SV545 package includes the lens and a complete accessory set for mounting and setup (carry bag, dovetail hardware, bracket parts, timing components, and tools as supplied by the manufacturer).


Specifications
| Brand | SVBONY |
| Model | SV545 |
| Optical Design | Petzval (5 elements in 3 groups) |
| Clear Aperture | 45mm |
| Focal Length | 203mm |
| Focal Ratio | f/4.5 |
| Coatings | FMC (Fully Multi-Coated) |
| Focuser | Integrated helical |
| Image Circle | 44mm |
| Rotation | Lockable 360° rotator (CAA) |
| Rear Connection | M48x0.75 male thread |
| Mounting | Dovetail plate (double-sided style) |
FAQ
Is the SV545 suitable for full-frame cameras?
Yes—its 44mm image circle is designed to support full-frame sensors, while also working beautifully with APS-C and smaller formats.
Do I need an additional field flattener?
In most setups, no. The SV545 uses a Petzval design with a built-in field flattener, so you typically don’t need to add one.
Can I use 2" filters?
Yes—this lens supports a 2" filter holder and uses a common M48 interface for straightforward filter/camera integration.
Is an EAF included?
No—an EAF is not included. The SV545 includes mounting support for EAF-style focusing upgrades, depending on your chosen motor and configuration.
Before connecting your camera
Check the adapter threads and the focus range with your camera, filter holder and any additional accessories in place. Integrated field correction removes the need for a separate conventional flattener, but it does not remove the need to reach focus or keep the sensor square to the optical axis. An electronic focus motor needs its own compatible mounting and control arrangement.
