EYSDON · 5× BARLOW · 1.25-INCH

Explore higher magnification

A substantial increase in image scale, a metal body and a built-in T2 camera thread. The EYSDON 90451 brings nominal 5× amplification to a compatible 1.25-inch telescope setup.

Upright EYSDON 90451 5× Barlow lens showing its metal body and T2 camera thread
5×Nominal amplification
1.25″Telescope & eyepiece fit
T2 threadM42 × 0.75 mm

Placed between the telescope and eyepiece, this Barlow increases the effective focal length of the system. It gives you a higher-power option with an existing eyepiece, while the external T2 thread offers a connection for a suitable camera adapter. Multi-coated optical glass sits inside a black metal body, with an eyepiece retaining screw to secure the eyepiece.

Is 5× right for your setup?

Five-times amplification is a large step. It can be useful for exploring lunar and planetary targets when your telescope's aperture, focus and the atmospheric conditions support the resulting magnification. Start with a longer-focal-length eyepiece and a steady mount.

A worked example

A 1,000 mm telescope with a 25 mm eyepiece gives 40× magnification. Applying the nominal 5× factor gives approximately 200×. This is an illustration, not a recommended setting for every telescope.

Higher power narrows the true field of view and can make the image dimmer. If the view becomes soft or unsteady, reduce the magnification: a larger image does not automatically reveal more detail.

Check the fit. Then connect.

For eyepieces: use an appropriate 1.25-inch telescope holder and 1.25-inch eyepiece. Check that the assembly seats securely and that your telescope has enough focus travel.

For a camera: the external thread is T2 / M42 × 0.75 mm. Connecting a DSLR or mirrorless camera through this thread requires a camera-specific T-ring, sold separately. Other cameras may connect directly or require a matching adapter. Check the thread pitch, camera mount and available focus travel before choosing your connection.

Actual amplification depends on the spacing between the Barlow optics and the eyepiece or camera sensor. A camera arrangement will not necessarily deliver exactly 5×.

Specifications

Brand / model EYSDON 90451
Nominal amplification 5×
Telescope interface 1.25″ / approximately 31.7 mm
Optical construction Optical glass; single concave lens
Coating Multi-coated
Camera thread External T2, M42 × 0.75 mm
Eyepiece insertion depth 27 mm
Body / finish Metal / black

What's included

One EYSDON 90451 5× Barlow lens and two dust caps.

Eyepiece, camera and camera adapter are not included.

EYSDON 90451 Barlow lens with its optical cell shown separately beside the barrel
Optical assembly detail: one Barlow shown partly disassembled.

Choosing the right optical accessory?

Compare Barlow lenses & extenders · Explore filters & optics
