SVBONY SV161 1.25 inch Double Helical Focuser - F9173B
The SVBONY SV161 double helical focuser adds 10 mm of fine focus travel to a compatible optical setup. Its non-rotating holder keeps a camera or eyepiece at the same orientation while you turn the focusing ring, making small focus adjustments easier to control.

Fine adjustment without rotating the camera
The helical adjustment moves the accessory along the optical axis while retaining its orientation. This is useful for a guide camera or other lightweight imaging arrangement where refocusing should not alter the framing. A graduated ring provides a visual reference for the adjustment, and the locking screw secures the selected position.
Compact metal construction
The CNC-machined aluminium body weighs 100 g. Its height changes from 43 mm to 53 mm across the focusing range. Allow for this physical length when planning a camera connection; the focuser is for fine adjustment and does not replace a large amount of coarse telescope focus travel.
Compatibility and setup
Check both mating interfaces and the available focus range before ordering. The holder accepts suitable 1.25-inch accessories, while the T2 connections provide a threaded option. Match thread gender as well as diameter and pitch; additional adapters may be required for your telescope.
Technical specifications
| Specification | Details |
|---|---|
| Model / SKU | SV161 / F9173B |
| Accessory holder | 1.25 inch |
| Telescope-side thread | Female T2 / M42 × 0.75 |
| Camera-side thread | Male T2 / M42 × 0.75 |
| Focus travel | 10 mm |
| Height range | 43–53 mm |
| Manufacturer-stated adjustment accuracy | 0.05 mm |
| Material | CNC-machined aluminium |
| Weight | 100 g |
What's included
- SV161 double helical focuser
- Three M3 screws
