Description

SVBONY · SV193 · W9152A

A wider imaging field for your original SV503 70ED

The SVBONY SV193 W9152A combines 0.8× focal reduction with field flattening for the original SV503 70mm f/6 ED doublet refractor. It shortens the telescope’s focal length and corrects field curvature, making it a practical upgrade for photographing larger nebulae, star fields and extended deep-sky targets.

0.8×
Focal reduction
336mm
Calculated focal length*
f/4.8
Calculated focal ratio*
55mm
Nominal back focus

*Calculated from the original telescope’s 420mm focal length and f/6 focal ratio using the nominal 0.8× reduction factor.

SVBONY SV193 W9152A reducer and field flattener for the original SV503 70ED refractor
W9152A is the version matched to the original SV503 70ED. Check the telescope model and revision before ordering.

Compatibility: choose the correct 70ED

This listing is for the original SV503 70mm f/6, 420mm doublet. The newer SV503 70mm f/6.78, 474mm flat-field telescope has a built-in corrector and a different optical design. Compatibility with that newer version is not established for W9152A; please contact us before ordering for it.

The SV193 versions for the 80ED and 102ED are different products. W9152A uses an M54 × 0.75 telescope connection; it should not be selected simply because another telescope has a 2-inch focuser or a matching thread.

What changes in your images?

More sky on the same sensor. Reducing the focal length from 420mm to approximately 336mm gives about 25% more coverage across each image dimension, calculated from the nominal reduction factor. This can make framing extended targets easier and reduce the number of mosaic panels needed for a particular field.

A flatter field for astrophotography. A refractor’s curved focal surface can leave stars away from the centre out of focus when a flat camera sensor is used. The matched flattener addresses that curvature. Accurate spacing, focus and camera alignment still matter; a corrector cannot compensate for tracking errors or mechanical tilt.

A faster f/4.8 imaging system. The reduced focal ratio can help collect signal from extended objects more quickly per pixel with the same camera. It also changes the image scale, so targets appear smaller on the sensor. Exposure choices still depend on the camera, sky brightness, filters and tracking.

Connecting your camera and setting the spacing

  1. Confirm the telescope. Check that it is the original 420mm f/6 SV503 70ED before assembling the imaging train.
  2. Use the matched threaded interface. The telescope-side connection is M54 × 0.75 and the camera-side connection is M48 × 0.75. Check the mating thread and adapter requirements for your equipment; never force an incompatible fitting.
  3. Build towards 55mm back focus. Measure from the reducer’s camera-side reference shoulder to the camera sensor plane. Include the camera’s own sensor recess and every adapter or accessory in that distance.
  4. Focus and inspect a star field. Check the centre and corners. Small spacing adjustments may help optimise the result, while uneven corner behaviour can also indicate tilt.

A DSLR or mirrorless camera needs the correct camera-specific adapter with a compatible M48 connection. Do not assume a camera body alone provides 55mm spacing. With an astronomy camera, allow for its stated sensor depth before choosing extension rings. A filter drawer, filter wheel or off-axis guider must fit within the spacing budget; filters can also affect the optimum optical spacing.

W9152A specifications

Specification W9152A
Brand / model SVBONY SV193
Product code W9152A
Matched telescope Original SV503 70mm f/6 ED doublet
Function 0.8× focal reducer and field flattener
Nominal back focus 55mm
Telescope connection M54 × 0.75
Camera connection M48 × 0.75
Optical construction 3 elements in 3 groups
Lens coatings Fully multi-coated (FMC)
Blackened lens edges Yes
Net weight 273g
Calculated focal length / ratio Approximately 336mm / f/4.8 on the original 420mm f/6 telescope

What you are buying

One SVBONY SV193 W9152A reducer / field flattener. The telescope, camera, camera-specific T-ring, extension spacers and other imaging accessories are separate purchases. Choose those parts to suit your exact camera and spacing requirements.

Common questions

Will it fit every 70mm refractor?

No. Aperture and thread size alone do not establish optical compatibility. This version is matched to the original SV503 70ED f/6 doublet.

Can I use it on the newer flat-field SV503 70mm?

Do not assume compatibility. That telescope has a different focal length and an internal corrector. Tell us which version you own before buying an additional reducer.

Does 55mm mean the focuser travel?

No. It is the spacing behind the reducer to the sensor. Once that imaging train is assembled, the telescope focuser brings the system into focus.

Is full-frame corner performance guaranteed?

No corrected image-circle diameter is specified here for W9152A. Check suitability for your camera before ordering, especially if edge performance across a large sensor is a priority.

Need help planning your imaging train?

Tell Dark Clear Skies your telescope version, camera model and any filters, drawer or guider you intend to use. We can help you check the connections and spacing before you choose adapters.

SVBONY SV193 0.8× Reducer / Field Flattener for SV503 70ED – W9152A

Sale price £129.00
Or £43.00 × 3 interest-free with PayPal
£179.00 £50.00 OFF

In stock · 9 available

W9152A

SVBONY · SV193 · W9152A

A wider imaging field for your original SV503 70ED

The SVBONY SV193 W9152A combines 0.8× focal reduction with field flattening for the original SV503 70mm f/6 ED doublet refractor. It shortens the telescope’s focal length and corrects field curvature, making it a practical upgrade for photographing larger nebulae, star fields and extended deep-sky targets.

0.8×
Focal reduction
336mm
Calculated focal length*
f/4.8
Calculated focal ratio*
55mm
Nominal back focus

*Calculated from the original telescope’s 420mm focal length and f/6 focal ratio using the nominal 0.8× reduction factor.

SVBONY SV193 W9152A reducer and field flattener for the original SV503 70ED refractor
W9152A is the version matched to the original SV503 70ED. Check the telescope model and revision before ordering.

Compatibility: choose the correct 70ED

This listing is for the original SV503 70mm f/6, 420mm doublet. The newer SV503 70mm f/6.78, 474mm flat-field telescope has a built-in corrector and a different optical design. Compatibility with that newer version is not established for W9152A; please contact us before ordering for it.

The SV193 versions for the 80ED and 102ED are different products. W9152A uses an M54 × 0.75 telescope connection; it should not be selected simply because another telescope has a 2-inch focuser or a matching thread.

What changes in your images?

More sky on the same sensor. Reducing the focal length from 420mm to approximately 336mm gives about 25% more coverage across each image dimension, calculated from the nominal reduction factor. This can make framing extended targets easier and reduce the number of mosaic panels needed for a particular field.

A flatter field for astrophotography. A refractor’s curved focal surface can leave stars away from the centre out of focus when a flat camera sensor is used. The matched flattener addresses that curvature. Accurate spacing, focus and camera alignment still matter; a corrector cannot compensate for tracking errors or mechanical tilt.

A faster f/4.8 imaging system. The reduced focal ratio can help collect signal from extended objects more quickly per pixel with the same camera. It also changes the image scale, so targets appear smaller on the sensor. Exposure choices still depend on the camera, sky brightness, filters and tracking.

Connecting your camera and setting the spacing

  1. Confirm the telescope. Check that it is the original 420mm f/6 SV503 70ED before assembling the imaging train.
  2. Use the matched threaded interface. The telescope-side connection is M54 × 0.75 and the camera-side connection is M48 × 0.75. Check the mating thread and adapter requirements for your equipment; never force an incompatible fitting.
  3. Build towards 55mm back focus. Measure from the reducer’s camera-side reference shoulder to the camera sensor plane. Include the camera’s own sensor recess and every adapter or accessory in that distance.
  4. Focus and inspect a star field. Check the centre and corners. Small spacing adjustments may help optimise the result, while uneven corner behaviour can also indicate tilt.

A DSLR or mirrorless camera needs the correct camera-specific adapter with a compatible M48 connection. Do not assume a camera body alone provides 55mm spacing. With an astronomy camera, allow for its stated sensor depth before choosing extension rings. A filter drawer, filter wheel or off-axis guider must fit within the spacing budget; filters can also affect the optimum optical spacing.

W9152A specifications

Specification W9152A
Brand / model SVBONY SV193
Product code W9152A
Matched telescope Original SV503 70mm f/6 ED doublet
Function 0.8× focal reducer and field flattener
Nominal back focus 55mm
Telescope connection M54 × 0.75
Camera connection M48 × 0.75
Optical construction 3 elements in 3 groups
Lens coatings Fully multi-coated (FMC)
Blackened lens edges Yes
Net weight 273g
Calculated focal length / ratio Approximately 336mm / f/4.8 on the original 420mm f/6 telescope

What you are buying

One SVBONY SV193 W9152A reducer / field flattener. The telescope, camera, camera-specific T-ring, extension spacers and other imaging accessories are separate purchases. Choose those parts to suit your exact camera and spacing requirements.

Common questions

Will it fit every 70mm refractor?

No. Aperture and thread size alone do not establish optical compatibility. This version is matched to the original SV503 70ED f/6 doublet.

Can I use it on the newer flat-field SV503 70mm?

Do not assume compatibility. That telescope has a different focal length and an internal corrector. Tell us which version you own before buying an additional reducer.

Does 55mm mean the focuser travel?

No. It is the spacing behind the reducer to the sensor. Once that imaging train is assembled, the telescope focuser brings the system into focus.

Is full-frame corner performance guaranteed?

No corrected image-circle diameter is specified here for W9152A. Check suitability for your camera before ordering, especially if edge performance across a large sensor is a priority.

Need help planning your imaging train?

Tell Dark Clear Skies your telescope version, camera model and any filters, drawer or guider you intend to use. We can help you check the connections and spacing before you choose adapters.
