More aperture in a compact lunar and planetary telescope
The SVBONY MK105 combines a 105 mm aperture with a 1365 mm focal length in a folded Maksutov-Cassegrain optical tube. It offers a step up in aperture from the MK90 for observers who want a compact tube with more light-collecting area.
Optical tube assembly only. Choose a suitable mount, eyepiece and viewing accessories separately.

What is it best for?
The MK105's long focal length makes useful lunar and planetary magnifications accessible with ordinary eyepieces. Explore the changing shadows around lunar craters, follow Jupiter's brighter cloud belts when conditions allow, or observe Saturn's rings and suitable double stars.
A compact Maksutov is a different choice from a short, wide-field refractor. It suits relatively small targets; the largest nebulae and sweeping star fields will not fit into the same narrow field at typical magnifications. Fainter deep-sky objects also depend strongly on sky darkness, aperture and observing experience.
Why a short tube can have a long focal length
The corrector and mirrors fold the optical path inside the tube, giving the telescope a much longer effective focal length than its external size suggests. Internal focusing adjusts focus without a long external drawtube.
Treat the front corrector as an optical surface: avoid touching it and protect it from dew and dust. A closed-tube design still needs time to settle towards the outside temperature before you judge fine detail.

Match the magnification to the night
Magnification is telescope focal length divided by eyepiece focal length. At the nominal 1365 mm focal length, the examples below show the approximate powers of separately supplied eyepieces.
| 25 mm eyepiece | 55× |
|---|---|
| 15 mm eyepiece | 91× |
| 10 mm eyepiece | 137× |
| 8 mm eyepiece | 171× |
These are calculations, not a promise that every power will be useful every night. Begin with the lowest power, centre the target, then increase magnification only while the detail remains clear. More magnification can make a blurred or unsteady image larger without revealing more.
Complete your visual setup
The OTA is not a complete observing kit. You need a mount that accepts the Vixen-style dovetail and supports the complete load, plus a compatible diagonal and eyepiece for comfortable astronomical viewing. Add a suitable finder if you want easier target acquisition. Confirm rear clearance when the telescope points high in the sky.
Accessory connections
The telescope has a 1.25-inch visual accessory interface and an M42 × 0.75 T-thread for suitable photographic adaptation. A camera-specific T-ring or camera adapter is separate. The presence of a T-thread does not guarantee that every camera and extension combination will reach focus.
For terrestrial use, choose a suitable image-erecting accessory if you want a normally oriented view. A conventional astronomical mirror diagonal normally reverses left and right.
Imaging options
A compatible planetary camera or appropriately adapted camera can be used for lunar and planetary imaging. A suitable tracking mount helps keep the target on the sensor during a video or exposure sequence.
The relatively long focal length and slow focal ratio make this a more demanding starting point for long-exposure deep-sky imaging than a short refractor. Choose the telescope around the subjects you want to record.
Choose the SVBONY Maksutov that suits your setup
| Model | Aperture / focal length | Stated OTA weight | Reason to choose it |
|---|---|---|---|
| MK90 | 90 mm / 1250 mm | 1.38 kg | Lightest option for compact lunar and planetary observing |
| MK105 | 105 mm / 1365 mm | 2.193 kg | Aperture step up while retaining a manageable tube |
| MK127 | 127 mm / 1500 mm | 2.934 kg | Largest aperture here, dual-speed focus and supplied reducer |
Technical specifications
| Model / SKU | MK105 / F9382A |
|---|---|
| Optical design | Maksutov-Cassegrain |
| Aperture | 105 mm |
| Native focal length | 1365 mm |
| Native focal ratio | f/13 |
| Focusing | Internal |
| Stated net OTA weight | 2.193 kg |
| Telescope mounting | Vixen-style dovetail |
| Dovetail plate length | 160 mm |
| Photographic / rear thread | M42 × 0.75 T-thread |
| Tube length | 377 mm |
| Tube outer diameter | 119 mm |
What's included?
- 1 × SVBONY MK105 optical tube assembly
- 1 × versatile finder mounting base
- 1 × 160 mm Vixen-style dovetail plate
A mount, tripod, finder, diagonal, eyepieces and camera are not included. Other equipment shown in setup or demonstration images is for illustration.

Questions before you buy
Will I be able to use it immediately without anything else?
You need a suitable mount and viewing accessories. This listing supplies the optical tube and the hardware listed above, rather than a complete telescope kit.
Can I see fine planetary detail?
The telescope can show lunar and planetary features when correctly focused and supported. Atmospheric steadiness, target altitude, acclimatisation and your observing conditions govern the detail visible.
Can I use a phone to photograph through it?
With a suitable eyepiece and phone adaptor you can record the eyepiece view. The MSM Tridapter is one option; check the eyepiece housing diameter and phone width before choosing an adaptor.
Should I adjust collimation straight away?
Do not adjust optical alignment as a routine first step. Check focus, thermal settling and atmospheric conditions first. Seek advice if a careful star test suggests an alignment problem.
